| Tonnage Class | 2.0TR | |
|---|---|---|
| Model | RMQG024HFEOEZ1 | |
| Compressor | Type | Rotary |
| Rated Power Supply | Volts/Hz/Phase | 230/50/1 |
| Rated Cooling Capacity (100 % load) | BTU | 21500 |
| Maximum Cooling Capacity | 21500 | |
| Rated Cooling Capacity (100 % load) | Watts | 6300 |
| Maximum Cooling Capacity | 6300 | |
| Rated Power Input (100 % load) | Watts | 2000 |
| Rated EER | (kWh) | 3.15 |
| Rated AEER | 3.1 | |
| MEPS | 2.93 | |
| Current Drawn (Rated) | Amps | 9.2 |
| Fan Speed | Steps | 3 |
| Air Flow (IDU) (Cooling -Super High) | CFM | 583 |
| Sound Level* (IDU) | dB | 38 |
| Dimension (IDU) (W X H X D) | mm | 968x294x240 |
| Dimension (ODU) (W X H X D) | mm | 792 X 600 X 299 |
| Net Weight (IDU) | Kg | 11 |
| Net Weight (ODU) | Kg | 39 |
| Refrigerant Pipe Diameter | Inches | 1/4" X 5/8" |
| Maximum Piping length | Mtr | 25 |
